Plastic pipe butt-welding machine
The HÜRNER CNC ECO 2.0 is a high-quality and durable, next-generation CN-controlled plastic pipe butt-welding machine that has been developed in compliance, as applicable, with the machinery directive 2006/42/EC as amended as well as the ISO standard 12176-1 and the DVS standard 2207-1. The design of the machine is such that with 12 basic machine chassis models, pipes from O.D. 40 through 1600 mm (1 ½” – 63”) can be joined.
The welding machines ship with a fully encased CNC hydraulic and control box of ingress protection IP 54 managing pressures of up to 220 bar. Both the anti-stick-coated heating element and the facing tool are hooked up along with the machine chassis to the hydraulic and control unit. No additional power distribution is needed.
Technical Data | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Dimension | 160 mm | 200 mm | 250 mm | 315 mm | 355 mm | 500 mm | 630 mm | 800 mm | 1000 mm | 1200 mm | 1400 mm | 1600 mm |
Operating range, O.D. | 40 - 160 mm | 63 - 200 mm | (63) 75 - 250 mm | 90 - 315 mm | 90 - 355 mm | 200 - 500 mm | 315 - 630 mm | 500 - 800 mm | 630 - 1000 mm | 630 - 1200 mm | 800 - 1400 mm | 800 - 1600 mm |
Power supply | 230 V | 230 V | 230 V | 230 V | 230 V | 400 V | 400 V | 400 V | 400 V | 400 V | 400 V | 400 V |
Frequency | 50 Hz | 50 Hz | 50 Hz | 50 Hz | 50 Hz, 3 ph. | 50 Hz, 3 ph. | 50 Hz, 3 ph. | 50 Hz, 3 ph. | 50 Hz, 3 ph. | 50 Hz, 3 ph. | 50 Hz, 3 ph. | 50 Hz, 3 ph. |
Rated power | 3.94 kW | 4.68 kW | 4.94 kW | 5.44 kW | 5.45 kW | 12.54 kW | 13 kW | 19.54 kW | 23.6 kW | 24.6 kW | 45.5 kW | 55.5 kW |
Overall weight incl. all components |
80 kg | 91 kg | 125 kg | 179 kg | 216 kg | 372 kg | 581 kg | 1233 kg | 1397 kg | 1775 kg | ~ 3800 kg | ~ 4800 kg |
Reducer inserts | 40 - 140 | 63 - 180 | (63), 75 - 225 | 90 - 280 | 90 - 315 | 200 - 450 | 315 - 560 | 500 - 710 | 630 - 900 | 630 - 1000 | 800 - 1200 | 800 - 1400 |
- Operating range 160 mm - 200 mm
- Operating range 250 mm - 315 mm - 350 mm
